| Quantity: | |
|---|---|
DC12025
| Mode | #Bearing Type | Rated Voltage | Qperating Voltage | Input Current | Input Power | Speed | MaxAir Flow | Max Static Pressure | Noise | Weigh | ||
| Part No. | B.S | VDC | VDC | Amp | Watt | RPM | CFM | m³/min | Inch-H₂O | Pa | dB-A | g |
| DA12025#12U | B.S | 12 | 7.0-13.8 | 0.80 | 9.60 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| DA12025#12H | B.S | 12 | 7.0-13.8 | 0.50 | 6.00 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| DA12025#12M | B.S | 12 | 7.0-13.8 | 0.40 | 4.80 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| DA12025#12L | 8.S | 12 | 7.0-13.8 | 0.20 | 2.40 | 2000 | 67.01 | 1.90 | 0.1 | 26.09 | 35.00 | 140.00 |
| DA12025#24U | B.S | 24 | 14.0-27.6 | 0.50 | 12.00 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| DA12025#24H | B.S | 24 | 14.0-27.6 | 0.40 | 960.00 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| DA12025#24M | B.S | 24 | 14.0-27.6 | 0.25 | 6.00 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| DA12025#24L | B.S | 24 | 14.0-27.6 | 0.15 | 3.60 | 2000 | 67.01 | 1.90 | 0.1 | 26.09 | 35.00 | 140.00 |
| DA12025#48U | B.S | 48 | 28.0-56.0 | 0.40 | 19.20 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| DA12025#48H | B.S | 48 | 28.0-56.0 | 0.30 | 14.40 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| DA12025#48M | B.S | 48 | 28.0-56.0 | 0.20 | 9.60 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| DA12025#48L | B.S | 48 | 28.0-56.0 | 0.10 | 4.80 | 2000 | 67.01 | 1.90 | 0.1 | 26.09 | 35.00 | 140.00 |
Key Features:
Effective High-Airflow Cooling: Offers robust airflow to ensure optimal heat dissipation.
Quiet Operation Design: Carefully crafted to keep noise levels low while delivering efficient cooling.
Long-Lasting Durability: Constructed with superior materials for sustained reliability and performance.
Energy-Efficient Cooling: Achieves powerful cooling with minimal power usage.
Simple Installation: User-friendly design for easy setup in various environments.
Versatile Use: Ideal for a wide range of cooling needs, from computer systems to industrial applications.
Applications:
PC and Server Cooling: Perfect for keeping high-end computers and servers cool, ensuring stable operation.
Industrial Equipment Ventilation: Great for providing effective cooling in industrial settings, where consistent performance is essential.
Cooling in Large Electronic Devices: Suitable for maintaining appropriate temperatures in larger electronic systems.
| Mode | #Bearing Type | Rated Voltage | Qperating Voltage | Input Current | Input Power | Speed | MaxAir Flow | Max Static Pressure | Noise | Weigh | ||
| Part No. | B.S | VDC | VDC | Amp | Watt | RPM | CFM | m³/min | Inch-H₂O | Pa | dB-A | g |
| DA12025#12U | B.S | 12 | 7.0-13.8 | 0.80 | 9.60 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| DA12025#12H | B.S | 12 | 7.0-13.8 | 0.50 | 6.00 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| DA12025#12M | B.S | 12 | 7.0-13.8 | 0.40 | 4.80 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| DA12025#12L | 8.S | 12 | 7.0-13.8 | 0.20 | 2.40 | 2000 | 67.01 | 1.90 | 0.1 | 26.09 | 35.00 | 140.00 |
| DA12025#24U | B.S | 24 | 14.0-27.6 | 0.50 | 12.00 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| DA12025#24H | B.S | 24 | 14.0-27.6 | 0.40 | 960.00 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| DA12025#24M | B.S | 24 | 14.0-27.6 | 0.25 | 6.00 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| DA12025#24L | B.S | 24 | 14.0-27.6 | 0.15 | 3.60 | 2000 | 67.01 | 1.90 | 0.1 | 26.09 | 35.00 | 140.00 |
| DA12025#48U | B.S | 48 | 28.0-56.0 | 0.40 | 19.20 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| DA12025#48H | B.S | 48 | 28.0-56.0 | 0.30 | 14.40 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| DA12025#48M | B.S | 48 | 28.0-56.0 | 0.20 | 9.60 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| DA12025#48L | B.S | 48 | 28.0-56.0 | 0.10 | 4.80 | 2000 | 67.01 | 1.90 | 0.1 | 26.09 | 35.00 | 140.00 |
Key Features:
Effective High-Airflow Cooling: Offers robust airflow to ensure optimal heat dissipation.
Quiet Operation Design: Carefully crafted to keep noise levels low while delivering efficient cooling.
Long-Lasting Durability: Constructed with superior materials for sustained reliability and performance.
Energy-Efficient Cooling: Achieves powerful cooling with minimal power usage.
Simple Installation: User-friendly design for easy setup in various environments.
Versatile Use: Ideal for a wide range of cooling needs, from computer systems to industrial applications.
Applications:
PC and Server Cooling: Perfect for keeping high-end computers and servers cool, ensuring stable operation.
Industrial Equipment Ventilation: Great for providing effective cooling in industrial settings, where consistent performance is essential.
Cooling in Large Electronic Devices: Suitable for maintaining appropriate temperatures in larger electronic systems.
