| Quantity: | |
|---|---|
DC12025
| Mode | #Bearing Type | Rated Voltage | Qperating Voltage | Input Current | Input Power | Speed | MaxAir Flow | Max Stati Pressure | Noise | Weigh | ||
| Part No. | B.S | VDC | VDC | Amp | Watt | RPM | CFM | m³/min | Inch-H₂O | Pa | dB-A | g |
| DA12038#12U | B.S | 12 | 7.0-13.8 | 1.50 | 18.00 | 4000 | 165.05 | 4.67 | 0.60 | 150.63 | 58.00 | 262.00 |
| DA12038#12H | B.S | 12 | 7.0-13.8 | 1.00 | 12.00 | 3500 | 144.21 | 4.08 | 0.50 | 124.25 | 53.00 | 262.00 |
| DA12038#12M | B.S | 12 | 7.0-13.8 | 0.60 | 7.20 | 3000 | 115.29 | 3.27 | 0.34 | 83.55 | 48.00 | 262.00 |
| DA12038#12L | B.S | 12 | 7.0-13.8 | 0.40 | 4.80 | 2500 | 101.85 | 2.88 | 0.26 | 64.63 | 40.00 | 262.0 |
| DA12038#24U | B.S | 24 | 14.0-27.6 | 1.00 | 24.00 | 4000 | 165.05 | 4.67 | 0.60 | 150.63 | 58.00 | 262.00 |
| DA12038#24H | B.S | 24 | 14.0-27.6 | 0.60 | 14.40 | 3500 | 144.21 | 4.08 | 0.50 | 124.25 | 53.00 | 262.0 |
| DA12038#24M | 8.S | 24 | 14.0-27.6 | 0.40 | 9.60 | 3000 | 115.29 | 3.27 | 0.34 | 83.55 | 48.00 | 262.0 |
| DA12038#24L | B.S | 24 | 14.0-27.6 | 0.20 | 4.80 | 2500 | 101.85 | 2.88 | 0.26 | 64.63 | 40.00 | 262.00 |
| DA12038#48U | B.S | 48 | 28.0-56.0 | 0.60 | 28.80 | 4000 | 165.05 | 4.67 | 0.60 | 150.63 | 58.00 | 262.00 |
| DA12038#48H | B.S | 48 | 28.0-56.0 | 0.40 | 19.20 | 3500 | 144.21 | 4.08 | 0.50 | 124.25 | 53.00 | 262.00 |
| DA12038#48M | B.S | 48 | 28.0-56.0 | 0.20 | 9.60 | 3000 | 115.29 | 3.27 | 0.34 | 83.55 | 48.00 | 262.00 |
| DA12038#48L | B.S | 48 | 28.0-56.0 | 0.12 | 5.76 | 2500 | 101.85 | 2.88 | 0.26 | 64.63 | 40.00 | 262.00 |
Key Features:
Strong Cooling Performance: Delivers significant airflow, effectively managing high heat scenarios.
Built for Durability: Features a construction meant to withstand rigorous industrial conditions.
Efficient Operation: Balances high-capacity cooling with energy efficiency.
Ease of Installation: Offers a straightforward installation process, fitting a variety of industrial settings.
Broad Application Scope: Excellently suited for tough environments, from cooling heavy machinery to industrial ventilation.
Applications:
Cooling Industrial Machinery: Ideal for keeping large industrial machines and equipment at optimal operating temperatures.
High-Performance Computing Systems: Suitable for data centers and high-end computing where strong cooling is necessary.
Large Space Ventilation: Effective in circulating air in expansive spaces like warehouses or production facilities.
| Mode | #Bearing Type | Rated Voltage | Qperating Voltage | Input Current | Input Power | Speed | MaxAir Flow | Max Stati Pressure | Noise | Weigh | ||
| Part No. | B.S | VDC | VDC | Amp | Watt | RPM | CFM | m³/min | Inch-H₂O | Pa | dB-A | g |
| DA12038#12U | B.S | 12 | 7.0-13.8 | 1.50 | 18.00 | 4000 | 165.05 | 4.67 | 0.60 | 150.63 | 58.00 | 262.00 |
| DA12038#12H | B.S | 12 | 7.0-13.8 | 1.00 | 12.00 | 3500 | 144.21 | 4.08 | 0.50 | 124.25 | 53.00 | 262.00 |
| DA12038#12M | B.S | 12 | 7.0-13.8 | 0.60 | 7.20 | 3000 | 115.29 | 3.27 | 0.34 | 83.55 | 48.00 | 262.00 |
| DA12038#12L | B.S | 12 | 7.0-13.8 | 0.40 | 4.80 | 2500 | 101.85 | 2.88 | 0.26 | 64.63 | 40.00 | 262.0 |
| DA12038#24U | B.S | 24 | 14.0-27.6 | 1.00 | 24.00 | 4000 | 165.05 | 4.67 | 0.60 | 150.63 | 58.00 | 262.00 |
| DA12038#24H | B.S | 24 | 14.0-27.6 | 0.60 | 14.40 | 3500 | 144.21 | 4.08 | 0.50 | 124.25 | 53.00 | 262.0 |
| DA12038#24M | 8.S | 24 | 14.0-27.6 | 0.40 | 9.60 | 3000 | 115.29 | 3.27 | 0.34 | 83.55 | 48.00 | 262.0 |
| DA12038#24L | B.S | 24 | 14.0-27.6 | 0.20 | 4.80 | 2500 | 101.85 | 2.88 | 0.26 | 64.63 | 40.00 | 262.00 |
| DA12038#48U | B.S | 48 | 28.0-56.0 | 0.60 | 28.80 | 4000 | 165.05 | 4.67 | 0.60 | 150.63 | 58.00 | 262.00 |
| DA12038#48H | B.S | 48 | 28.0-56.0 | 0.40 | 19.20 | 3500 | 144.21 | 4.08 | 0.50 | 124.25 | 53.00 | 262.00 |
| DA12038#48M | B.S | 48 | 28.0-56.0 | 0.20 | 9.60 | 3000 | 115.29 | 3.27 | 0.34 | 83.55 | 48.00 | 262.00 |
| DA12038#48L | B.S | 48 | 28.0-56.0 | 0.12 | 5.76 | 2500 | 101.85 | 2.88 | 0.26 | 64.63 | 40.00 | 262.00 |
Key Features:
Strong Cooling Performance: Delivers significant airflow, effectively managing high heat scenarios.
Built for Durability: Features a construction meant to withstand rigorous industrial conditions.
Efficient Operation: Balances high-capacity cooling with energy efficiency.
Ease of Installation: Offers a straightforward installation process, fitting a variety of industrial settings.
Broad Application Scope: Excellently suited for tough environments, from cooling heavy machinery to industrial ventilation.
Applications:
Cooling Industrial Machinery: Ideal for keeping large industrial machines and equipment at optimal operating temperatures.
High-Performance Computing Systems: Suitable for data centers and high-end computing where strong cooling is necessary.
Large Space Ventilation: Effective in circulating air in expansive spaces like warehouses or production facilities.
