280ร280ร80mm
Voltage:ย 115V / 230V
Performance:ย 40 CFM ยท 34 dB
AC Axial Fan Manufacturer โ Industrial Cooling Solutions
- High-airflow AC axial fans engineered for 24/7 industrial operation
- Sizes from 40mm to 254mm, voltages 110V / 220V / 380V
- CE ยท UL ยท RoHS certified
- 15+ years OEM/ODM experience serving 40+ countries
- CE
- UL
- cUL
- RoHS
Browse AC Axial Fans by Specification
AC axial fans are widely used for panel cooling, cabinet ventilation, and industrial equipment heat dissipation. Running directly from mains power with no external driver, they are the most cost-effective choice for continuous-duty cooling. Hongbo manufactures a full range of industrial AC axial fans โ including 120mm, 172mm, 225mm, and 280mm models โ engineered for stable airflow, low noise, and a 50,000+ hour service life.ย Dual-voltage (110V/220V) models are available for the South American market, alongside custom solutions for voltage, airflow, frame size, connector, and IP protection level (IP55 standard, IP65/IP68 optional).
Products Categories
Get A Free Quote
AC Axial Fan Specifications Overview
All performance values measured per AMCA 210 / ISO 5801 in our calibrated airflow chamber. Download the full datasheet
for installation drawings and certification documents.
| Model | Size (mm) | Voltage (VAC) | Power (W) | Speed (RPM) | Airflow (CFM) |
| HB8025-AC | 80 x 80 x 25 | 110, 220V | 12-15 | 2300-2750 | 19-23 |
| HB8038-AC | 80 x 80 x 38 | 110, 220V | 6-9.5 | 2300-3100 | 22-28 |
| HB9225-AC | 92 x 92 x 25 | 110, 220V | 6-16 | 1800-2800 | 23-37 |
| HB9238-AC | 92 x 92 x 38 | 110, 220V | 7-17 | 2250-2750 | 38-46 |
| HB11025-AC | 110 x 110 x 25 | 110, 220V | 8-22 | 1700-2900 | 45-71 |
| HB12025-AC | 120 x 120 x 25 | 110, 220V | 8-32 | 1800-2700 | 50-76 |
| HB12038-AC | 120 x 120 x 38 | 110, 220, 380V | 18-30 | 2200-3000 | 76-98 |
| HB12038-AC-7P | 120 x 120 x 38 | 110, 220V | 11-31 | 2100-3000 | 78-112 |
| HB15050-AC | 150 x 150 x 50 | 110, 220, 380V | 18-38 | 2200-2900 | 170-210 |
| HB17238-AC-C | 172 x 150 x 38 | 110, 220, 380V | 26-36 | 1400-3300 | 85-230 |
| HB17050-AC | 172 x 150 x 51 | 110, 220V | 25-37 | 1500-3100 | 105-235 |
| HB17050-AC-C | 172 x 150 x 51 | 110, 220V | 25-35 | 2850-3350 | 215-225 |
| HB17050-AC-7P | 172 x 150 x 51 | 110, 220V | 25-37 | 1500-3100 | 115-245 |
| HB1725-AC | โ 172 x 51 | 110, 220V | 25-37 | 1500-3100 | 105-235 |
| HB16060-AC | 160 x 160 x 60 | 110, 220, 380V | 23-30 | 2750-3150 | 194-223 |
| HB16062-AC | 160 x 160 x 62 | 110, 220, 380V | 30-39 | 2300-3050 | 220-275 |
| HB17055-AC | 170 x 150 x 55 | 110, 220V | 31-42 | 2800-3100 | 191-224 |
| HB18065-AC | 180 x 180 x 65 | 110, 220, 380V | 40-59 | 2700-3000 | 355-385 |
| HB20060-AC | 200 x 200 x 60 | 110, 220, 380V | 42-72 | 2100-2600 | 350-530 |
| HB21070-AC | 210 x 210 x 70 | 110, 220, 380V | 45-58 | 2550-2950 | 419-468 |
| HB22060-AC | ร220 x 60 | 220V | 53-56 | 2800-3150 | 357-386 |
| HB2509-AC | 250 x 250 x 90 | 110, 220V | 75-135 | 1900-2850 | 600-880 |
| HB20572-AC | 205 x 205 x 72 | 110, 220, 380V | 68-100 | 2800-3200 | 610-725 |
| HB22580-AC-7P | 225 x 225 x 80 | 110, 220, 380V | 54-76 | 2700-3100 | 597-661 |
| HB25489-AC-7P | ร254 x 89 | 110, 220, 380V | 67-177 | 2500-2650 | 955-993 |
| HB28080-AC | 280 x 280 x 80 | 110, 220, 380V | 126-148 | 2500-2800 | 1098-1160 |
- Operating temp: -10ยฐC to +70ยฐC (high-temp +85ยฐC)
- Die-cast aluminum frame, PBT impeller
- Insulation class B or F available
- Impedance-protected or thermal cut-off motor
- Lead wire: cable or terminal block
- Protection rating: IP55 standard, IP65/IP68 optional
- Anti-corrosion coating for outdoor / coastal use
- MTBF 50,000+ hrs @ 40ยฐC ball bearing
Where Hongbo AC Axial Fans Are Used
Selected for continuous-duty applications where stable cooling and equipment uptime matter.
Server & Telecom Cabinets
80โ172mm models for 19-inch rack cooling, switchgear ventilation, and network equipment. Impedance-protected motors prevent burnout when filters clog.
Industrial Control Panels
Cabinet cooling for VFDs, PLCs, contactors, and power converters. IP55-rated housings withstand dusty workshop environments.
HVAC & Refrigeration
Condenser and evaporator cooling, ducted ventilation, and rooftop unit airflow. Anti-corrosion coating available for outdoor installations.
Power Inverters & UPS
High-CFM 200mm+ models for solar inverters, EV chargers, and uninterruptible power supplies requiring sustained heat dissipation.
Welding & Industrial Equipment
High-temperature versions for inductive welders, transformers and laser cutting equipment.
Medical & Laboratory
Low-noise sleeve-bearing models (under 38 dB-A) for imaging systems, sterilizers, and clean-room environments.
What Our Clients Say
A South American panel builder needed one fan SKU that worked across mixed 110V and 220V sites. Our dual-voltage HB22060-AC let them stock a single part number instead of two, simplifying their inventory across three years of continuous supply
Control Panel OEM
Electrical Enclosures | Brazil
An Indian telecom OEM’s previous supplier kept failing when intake filters clogged. Our impedance-protected HB17251-AC ran through two monsoon seasons in outdoor base-station cabinets without a single field failure.
Telecom Cabinet Manufacturer
Telecom Equipment | India
A Brazilian UPS manufacturer needed a specific lead-wire length and connector to remove a separate wiring step on their line. We delivered the customized HB20060-AC in under a month and it has shipped in volume ever since.
UPS Manufacturer
Power Electronics | Brazil
Why Manufacturers Choose Hongbo Motor
AC axial fans are widely used for panel cooling, cabinet ventilation, and industrial equipment heat dissipation. Running directly from mains power with no external driver, they are the most cost-effective choice for continuous-duty cooling. Hongbo manufactures a full range of industrial AC axial fans โ including 120mm, 172mm, 225mm, and 280mm models โ engineered for stable airflow, low noise, and a 50,000+ hour service life.ย Dual-voltage (110V/220V) models are available for the South American market, alongside custom solutions for voltage, airflow, frame size, connector, and IP protection level (IP55 standard, IP65/IP68 optional).
50,000mยฒ Factory
In-house motor winding, die-casting, injection molding, and assembly. Monthly capacity 800,000+ units across the ac axial fan line.
Engineering QC
Anechoic chamber (10 dB-A background), calibrated airflow chamber up to 1,500 CFM, 100% Hi-POT testing, ISO 1940 G6.3 rotor balance.
Global Approvals
CE ยท UL / cUL ยท TรV ยท RoHS ยท REACH ยท EAC ยท ISO 9001:2015. Certified for sale in North America, EU, Japan, and SE Asia.
True ODM
In-house tool shop for custom frames and impellers. DFM review, 3D modeling, and prototypes within 7โ10 days.
Reliable Delivery
Stock models ship in 7 days. Custom orders: 25โ35 days for 5,000+ units. Real-time production photos and QC reports.
40+ Countries
Active suppliers to OEMs in Germany, USA, India, Turkey, Brazil, Korea, and 35+ other markets across HVAC, telecom, power, and medical.
Our Production Environment
We are factory direct sales, from consumers to stores to wholesalers to agents to general distributors to factory merchants,ย choose us to save a lot of intermediate links, to bring you the maximum profit margin!
FAQs
Is there a minimum order quantity (MOQ)?
No fixed MOQ. We accept orders of any size โ from a few pieces for prototyping up to container-scale volume production. Many long-term customers start with a small trial order to validate fit before scaling up. Tell us your quantity and we’ll quote accordingly.
Are samples free? How fast do they ship?
Yes โ samples are free. You only cover the courier cost (typically $30โ60 via DHL/FedEx, 3โ5 days door to door). Standard-model samples dispatch within 7 days of your request so you can evaluate real performance before committing.
What are your payment terms?
We accept T/T (telegraphic transfer / bank wire). For new orders the standard arrangement is a deposit with the balance before shipment; exact split is confirmed on the proforma invoice. Terms can be discussed for established repeat customers.
What warranty do you provide?
All Hongbo AC axial fans carry a 24-month warranty from the shipment date. Verified manufacturing defects are replaced free of charge in your next shipment or credited. Our field return rate is below 0.5%, and we run full root-cause analysis on any batch-level issue.
What's the lead time for a production order?
Standard models ship from stock within 7 days. Bulk orders of 5,000โ20,000 units take 25โ35 days. We confirm a firm ship date on the proforma invoice and send production progress photos at the midpoint of manufacturing.
Can I inspect the goods before shipment?
Yes. You’re welcome to send BV, SGS, TรV, or your own QC team to inspect before shipment. We also provide our own AQL 1.0 inspection report and 100% Hi-POT test records with every shipment at no extra charge.
What's the difference between an AC axial fan and a DC axial fan?
AC axial fans run directly from mains power (110V/220V/380V) and operate at a fixed speed determined by line frequency. They are simpler, cheaper, and ideal for continuous-duty cooling. DC axial fans run on low voltage (12V/24V/48V), allow variable speed via PWM, and consume less power โ but require a DC power source or driver. For a deeper comparison see ourย DC Fanย andย EC Fanย pages.
Do your fans have CE and UL certification?
Yes. All Hongbo AC axial fans carry CE marking and are UL/cUL recognized under file E******. We also support RoHS, REACH, and TรV certification for specific markets.
Can you customize the voltage, size, or connector?
Absolutely. We routinely customize frame dimensions, voltage (any value from 100V to 415V), lead wire length, connector type (AMP, JST, Molex, terminal block), impeller color, and product labeling. Send us a drawing or sample and we’ll match it.
What's the expected lifespan of your AC axial fans?
Ball-bearing models: 50,000โ70,000 hours at 40ยฐC. Sleeve-bearing models: 30,000โ40,000 hours. High-temperature versions tested up to 85ยฐC ambient.
Do you ship worldwide?
Yes โ sea freight (FOB Shenzhen / Yantian), air freight, and express (DHL, FedEx, UPS). DDP service available to USA, Germany, UK, and selected EU countries.
Can you supply matching fan guards and filters?
Yes. We manufacture finger guards, wire guards, and fan filter assemblies in all standard sizes โ see ourย Fan Guardย andย Fan Filterย categories.
Your OEM Order, Step by Step
From first inquiry to shipped goods. Most customers move from spec to sample in under two weeks.
Inquiry
Send specs โ size, voltage, airflow target, application. Reply in 12 hours.
Engineering
DFM review, recommended models, formal quotation.
Sample
Standard sample free. Custom prototype in 7โ10 days.
Production
Real-time progress reports and QC photos during production.
Shipping
100% Hi-POT test, AQL 1.0 sampling. FOB / CIF / DDP available.
